Beverage machine with an ergonomic water storage.

FIELD OF THE INVENTION

[0001] The field of the invention pertains to beverage preparation machines provided with an ergonomic water storage, e.g. machines using capsules of an ingredient of the beverage to be prepared.

[0002] For the purpose of the present description, a “beverage” is meant to include any human-consumable liquid substance, such as tea, coffee, hot or cold chocolate, milk, soup, baby food, etc... A “capsule” is meant to include any pre-portioned beverage ingredient, such as a flavouring ingredient, within an enclosing packaging of any material, in particular an airtight packaging, e.g. plastic, aluminium, recyclable and/or biodegradable packagings, and of any shape and structure, including soft pods or rigid cartridges containing the ingredient. The capsule may contain an amount of ingredient for preparing a single beverage portion or a plurality of beverage portions. BACKGROUND ART

[0003] Certain beverage preparation machines use capsules containing ingredients to be extracted or to be dissolved and/or ingredients that are stored and dosed automatically in the machine or else are added at the time of preparation of the drink. Some beverage machines possess filling means that include a pump for liquid, usually water, which pumps the liquid from a source of water that is cold or indeed heated through heating means, e.g. a thermoblock or the like.

[0004] Especially in the field of coffee preparation, machines have been widely developed in which a capsule containing beverage ingredients is inserted in a brewing device. The brewing device is tightly closed about the capsule, water is injected at the first face of the capsule, the beverage is produced in the closed volume of the capsule and a brewed beverage can be drained from a second face of the capsule and collected into a receptacle such as a cup or glass.

[0005] Ingredient mixing modules, e.g. brewing devices have been developed to facilitate insertion of a “fresh” capsule and removal of the capsule upon use. Typically, the brewing devices comprise two parts relatively movable from a configuration for inserting/removing a capsule to a configuration for brewing the ingredient in the capsule. The actuation of the movable part of the brewing device may be manual as disclosed in WO 2009/043630, WO 01/15581, WO 02/43541, WO 2010/015427, WO 2010/128109, WO 2011/144719 and WO 2012/032019. Various handle configurations are disclosed in EP 1867260, WO 2005/004683, WO WO2007/135136, WO 2008/138710, WO 2009/074550, WO 2009/074553, WO 2009/074555, WO 2009/074557, WO 2009/074559, WO 2010/037806, WO 2011/042400, WO 2011/042401 and WO 2011/144720. Integrations of such arrangements into beverage machines are disclosed in WO 2009/074550, WO2011/144719, EP2014195046, EP2014195048 and EP2014195067. The actuation of the movable part of the brewing device may be motorized, as for example disclosed in EP 1 767 129, WO 2012/025258, WO 2012/025259 and WO 2013/127476.
